Install HerdTrack
Congratulations if you’ve already purchased your HerdTrack system!
If not, this installation guide video will show you just how quick and easy it is to set up, because HerdTrack was developed by farmers, for farmers.
Install the hardware
Watch this short 4-minute video to learn how to install your HerdTrack system’s hardware
Here’s a cheat sheet to give you a quick guide through the installation steps
Step 1:
Install the scanner mount bracket
Secure the mount bracket to the back of the scanner using the provided screws and spanner.
Step 2:
Attach the mount bracket to the solar panel
Fix the 50mm mount bracket to the back of the solar panel and tighten the screws securely.
Step 3:
Connect the antenna
Screw the antenna gently onto the scanner’s antenna port without over-tightening.
Step 4:
Mount the scanner
Attach the scanner to the upright pole, ensuring it faces the direction of animal movement.
Step 5:
Mount the solar panel
Secure the solar panel to the 50mm upright pole, facing north for maximum sunlight.
Step 6:
Connect the solar panel to the scanner
Plug the solar panel cable into the scanner’s power port and ensure a firm connection.
Step 7:
Run diagnostics
Switch on the scanner, test signal strength with diagnostic tags, and check battery and solar performance.
Install the software
The installation guide video for the HerdTrack system’s software will be available soon.
Contact Us for support
If you experience any trouble with your installation, we’re here to help.
